Romer DUO plus - Refitting of the Belts (Left and Right)

GB
22
8.4. Refitting of the belts (left and right)
 First put the tongues 19 of the two
harness straps together and engage in the
buckle 17 (refer to 4.4).
 Feed the belt loop (black stitching) into the
cover and into the outer side slot 25 of the
seat shell.
25
 Slide the metal part 30 into the belt loop
(black stitching).
 Hook the belt loop into the long side of the
metal part 30.
 Push the belt loop back and hook into the
short side of the metal part 30.
30
 Pull the belt until the metal part 30 lies
straight against the seat shell.
25
30
 Feed the belt end 16 into cover.
 Fold the fabric cover (lower half) over the
outer edges of the seat shell.
 Clip the plastic insert of the cover into the
opening of the seat shell.
16
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
