GB
21
At the bottom
Take the elastic seam of the cover (lower
half) from the hooks in the seat shell.
Grasp the metal part 30 with which the
belt is secured to the seat shell, and pull
out.
25
30
Push the belt loop on the short side of the
metal part 30 back and unhook.
Slide the metal part 30 out of the belt loop.
30
Pull the belt out of side slot 25 of seat
shell and out of the cover.
25
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
