GB
15
• The tongues are difficult to insert (you feel resistance).
• The buckle only opens after applying extreme force.
Remedy
1. Removing the crotch belt 20
Open buckle 17 by pushing the red
release button 18.
Loosen the harness (refer to 4.2).
Open Velcro on crotch belt pad 21 and
take off.
Put seat shell into "sleeping" position
(refer to 6).
Grasp the metal plate under the seat shell,
with which the crotch belt 20 is secured to
the seat shell. Push it upwards, on its side,
through the belt slot 22.
18
17
21
20
22
2. Cleaning the buckle 17
Soak the buckle 17 in warm water (with dishwashing liquid) for an hour at
least. Rinse and dry thoroughly.
3. Refitting the crotch belt 20
Hold the metal plate sideways. Push it with the narrow side upwards through
the belt slot 22 in the cover and into the seat shell. Please check the
correct fitting of the metal plate by pulling up on the crotch belt 20
several times.
Feed Velcro of the crotch belt pad 21 into the crotch belt 20 and close.
Functional Problem
• The buckle tongues can no longer be inserted into the buckle housing.
Remedy
• Unlock buckle 17 by pushing the red release button 18.
5. Checklist for correct securing of your child
For the safety of your child, check that…
• the belts of the child seat are close to the body, without restricting the child.
• the shoulder belts are adjusted correctly (refer to 4.1).
• the shoulder pads lie correctly on the child's body.
• the belts are not twisted.
• the buckle tongues lock in the buckle housing.
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
