Romer DUO plus - Page 7

GB
7
 Using the green handle 2, pull the two
connectors 3 as far as they will go.
2
3
 On both sides of the seat squeeze the
locking button 5 and the red release
button 6 together and remove the
connector protection 33.
33
5
6
 The hook* 4 must be open on both
connectors 3. To open the hook squeeze
the locking button 5 and the red release
button 6 together (refer to engage
ISOFIX.)
3
4
3
4
 Position the two connectors 3 directly in
front of the two insertion guides 1.
1
3
3
1
2. Prepare TopTether
 Take the TopTether out of the fabric
pocket.
 Lift the metal tongue 27 away from the
strap 26 and pull the strap out with the
spring hook 31 to a V-shape.
 Place the strap behind the vehicle seat.
26
27
31
part number: 09163186 ( GM ) / 93181287 ( Vauxhall )
