Roper F Series - Parts List and Cross Sectionals

23
PARTS LIST & CROSS SECTIONALS
1
CASE
5
C ASE GASKET
8 (A,B,C,D)
PIPE PLUG
16
BEARING
20
BACKPLATE
22
CAP SCREW (HEX OR SOC HEAD)
23
BALL BEARING (MECH SEAL OR PACKING)
24
RETAINING RING (MECH SEAL OR PACKING)
25
LUBE FITTING
26
RETAINING RING
45
FACEPLATE
46
POPPET
47
BONNET
48
SPRING
49
SPRING GUIDE
50
GASKET, RELIEF VALVE CAP
51
RELIEF VALVE CAP
51A
PLUG CAP
52
NUT
53
ADJUSTING SCREW
54 (A)
GASLET. RELIEF VALVE
70
KEY, DRIVE
71
KEY, GEAR
72
DRIVE SHAFT (MECH SEAL OR PACKING)
73
IDLER SHAFT & GEAR
75
GEAR, RIGHT HAND
80
SOC OR HEX HD CAP SCREW (MECH SEAL OR PACKING
85
NUT, PACKING
86
PACKING GLAND CLIP
87
PACKING GLAND
89
STUD, PACKING
91
PACKING SET
92
PACKING WASHER
93
BRG CAGE MECH SEAL OR PACKING HOUSING, PACKING
93A
GASKET
96
MECH SEAL
KEY NO.'S
DESCRIPTIONS
NOTE: NOT ALL KEY NUMBERS ARE USED IN EVERY PUMP. THIS LIST IS GENERIC TO
ALL F-SERIES PUMPS.
