Replacing RES-102/RES-420 Page 3
Manual mode
Line frequency setting (50/60Hz)
RES-102
Selected by pressing the HAND key. The red ON
LED is lit continuously.
RES-440
Selected by pressing the HAND key ( ) while the
Home position is displayed.
ENTER
HAND
RESET
RES-102
Configured with plug-in jumper.
RES-420
Detected automatically in the 47…63Hz range.
Automatic detection
