Rosemount 8732 Series User Manual

Quick Installation Guide
00825-0100-4725, Rev BA
July 2003
Rosemount 8732/8700 Series
Identify Options and Configurations
The standard application of the 8732 includes a 4–20 mA output and
control of the flowtube coils. Other applications may require one or
more of the following configurations or options:
• Multidrop Communications
• Auxiliary Output
• Pulse Output
Additional options may apply. Be sure to identify those options and
configurations that apply to your situation, and keep a list of them
nearby for consideration during the installation and configuration
procedures.
Hardware Jumpers/Switches
The 8732 electronics board is equipped with
three user-selectable hardware switches. These switches set the
Failure Alarm Mode, Internal/External Analog Power, and Transmitter
Security. The standard configuration for these switches when shipped
from the factory are as follows:
Changing Hardware Switch Settings
In most cases, it is not necessary to change the setting of the
hardware switches. If you need to change the switch settings,
complete the steps outlined in the manual.
Failure Alarm Mode: HIGH
Internal/External Analog Power: INTERNAL
Transmitter Security: OFF
4725_revBA_qig.fm Page 6 Thursday, July 3, 2003 12:47 PM

Rosemount 8732 Series Specifications

General

Category	Measuring Instruments
Diagnostics	Yes
Measurement Type	Volumetric Flow
Output	4-20 mA, HART
Enclosure Rating	NEMA 4X, IP66
Communication Protocol	HART, FOUNDATION Fieldbus, Modbus
Product Type	Transmitter
Enclosure	Stainless Steel
Process Connection	Flanged
Material	Stainless Steel
Certifications	ATEX, IECEx, CSA, FM
Power Supply	11 to 42.4 VDC
Flow Range	0.04 to 12 m/s (0.13 to 39 ft/s)
