32 • DashBoard Menus SFC-6901 User Guide (v1.0)
Product Tab
Table 8 summarizes the read-only information displayed in the Product tab.
Hardware Tab
Table 9 summarizes the read-only information displayed in the Hardware tab.
SFP # (read-only) OK (Green) The video signal on the specific SFP channel
is a supported format and locked
Alarm suppressed
(Green)
The card is not monitoring the SFP channel
Unsupported Format
(Yellow)
A signal is detected on the specific SFP
channel but the video is not supported by
the card
Incompatible Video
(Yellow)
A signal is detected on the specific SFP
channel but its format is not compatible
with the output video format
Not time to Ref (Yellow) A signal is detected on the specific SFP
channel but the detected reference signal is
incompatible with this input signal
No Signal (Red) Indicates one of the following issues is
occurring:
• the SFP channel is not detected
• the system frame rate does not match the
input frame rate
Table 8 Product Tab
Item Parameters Description
Product SFC-6901
Supplier Ross Video Ltd.
Board Rev # Indicates the hardware version
Rear Module # Reports the rear module installed with the
card
Board S/N # Indicates the serial number of the card
Software Rev #.#-# Indicates the software version running on
the card
Table 9 Hardware Tab
Item Parameters Description
Voltage (mV) # Measured input millivolts
Current (mA) # Current consumption in milliamperes
CPU Headroom # Displays the CPU Load average
Table 7 Signal Tab
Item Parameters Description
