Configuration Tab
Table 10 summarizes the options displayed in the Configuration tab.
RAM Available # / # MB CPU Memory Used / Total CPU Memory
Configuration Bank # Storage count
Uptime (h) # Reports the number of hours since the last
reboot of the card
SFP #
SFP # Vendor # Reports the vendor details of the module
installed in the specified SFP port
SFP # P/N #
SFP # Status OK (Green) A supported SFP module is in the specified
SFP port and a valid signal is detected
Not Present (Yellow) No SFP Module is detected in the specified
SFP port
Unsupported (Red) The SFP Module is unsupported
Temperature #C Internal temperature (in Celsius) as
reported by the specified SFP port
Rx Power # #dBm Indicates the power at the optical input.
This value is accurate to ±3dBm.
Not Applicable A signal is not present on the SFP port
Tx Power # #dBm Indicates the power at the optical output
Not Applicable A signal is not present on the SFP port
Table 10 Configuration
Item Parameters Description
Gearbox Mode Bypass Gearbox The Gearbox settings are ignored. Refer to
Table 5 and Table 6 for I/O mapping.
DEMUX SL 6G -> QL 1.5G The SFC-6901 de-muxes a single-link
5.94Gbps input signal to four 1.485Gbps
output signals. Refer to Table 3 for I/O
mapping.
DEMUX SL 12G -> QL 3G The SFC-6901 de-muxes a single-link
11.88Gbps input signal to four 2.97Gbps
output signals. Refer to Table 3 for I/O
mapping.
MUX QL 1.5G -> SL 6G The SFC-6901 muxes four 1.485Gbps input
signals into a single-link 5.94Gbps output
signal. Refer to Table 4 for I/O mapping.
MUX QL 3G -> SL 12G The SFC-6901 muxes four 2.97Gbps input
signals into a single-link 11.88Gbps output
signal. Refer to Table 4 for I/O mapping.
