34 • DashBoard Menus SFC-6901 User Guide (v1.0)
Alarms Tab
Table 11 summarizes the options and read-only fields displayed in the Alarms tab.
Gearbox Status
(read-only)
Gearbox DEMUX OK
(Green)
The card is correctly operating in a DEMUX
mode with valid input and output signals
Gearbox MUX OK
(Green)
The card is correctly operating in a MUX
mode with valid input and output signals
Gearbox Pass-through
OK (Green)
The card is operating in Bypass mode with
valid input and output signals
Port #
IO Mode
a
Input Assigns the port on the rear module as an
input
Output Assigns the port on the rear module as an
output
Disabled (read-only) Indicates that the SFP port is not populated
Output Source SDI # Assigns an input signal when the IO Mode is
set to Output for the specified port
SFP #
Status # (Green) Reports the video format detected on the
specified port is present and supported
Incompatible Video
(Yellow)
An SDI signal is detected but it is in an
unsupported format or an error has
occurred
Signal Not Locked (Red) An SDI signal is detected but the system
frame rate does not match the input frame
rate
No Signal (Red) Indicates the absence of a valid SDI signal
on the specified port
a. This field is read-only when the SFP port is populated. The field automatically detects and reports the
function of the SFP module inserted into the specified port.
Table 11 Alarms Tab
Item Parameters Description
SFP # Hardware
Alarm Enable
Selected* The card reports a loss of the specified
input or if the format is incompatible for the
specified input
Cleared Disables this alarm
Gearbox Alarm
Enable
Selected* The card reports when the Gearbox mode
is set to Bypass
Cleared Disables this alarm
Alarm > Port
Table 10 Configuration
Item Parameters Description
