SFC-6901 User Guide (v1.0) DashBoard Menus • 35
Settings Tab
Table 12 summarizes the options displayed in the Settings tab.
SDI # Selected* The card reports a loss of the specified
signal or if the format is incompatible for
the specified port
Cleared Disables this alarm
SFP # Selected* The card reports a loss of the specified
signal or if the format is incompatible for
the specified port
Cleared Disables this alarm
Table 12 Settings Tab
Item Parameters Description
Edit Permission Unlocked All editable parameters in DashBoard can
be modified by a user
Locked The DashBoard interface is locked. The
editable parameters in DashBoard can no
longer be modified by the user.
To unlock the interface, select the box again
Factory Defaults Reset All editable parameters in DashBoard are
reset to the factory default values
Table 11 Alarms Tab
Item Parameters Description
