Rosslare AC-020 User Manual

AC-020 Page 16 03/02
Installation
The AC-020 has been designed for easy
installation. Only a few steps are required to
install the controller.
In this section you will learn how to mount the
controller in your desired location.
You will learn how to wire the controller to its
power source, which includes attaching the
controller to a rechargeable Lead Acid battery.
Wiring diagrams are also provided for attaching
the controller to the REX button and External 26-
Bit Wiegand Compatible readers.
Topics in this section:
• Mounting the Controller
• Power Wiring
• Typical Lock and Option Wiring
• Reader Wiring

Rosslare AC-020 Specifications

General

Brand	Rosslare
Model	AC-020
Category	Gateway
Language	English
