Page #19 background imageLoading...
Page #19 background image
Power Wiring
0
8
5
21
46
3
97
#
DOOR 1
DOOR 2
POWER SUPPLY
FROM
TRANSFORMER
16V AC (1.5A, 25VA)
(+)
(-)
12V DC LEAD ACID
BATTERY
UP TO 7 AH
RECOMMENDED
(+)
(-)
Typical Lock and Option Wiring
AC-020 Page 19 03/02
0
8
5
21
46
3
97
#
DOOR 1
DOOR 2
REX 2
(-)
N.O.
REX 1
N.O.
(-)
DOOR 1
DOOR 2
