Reader Functionality
AYC-Fx4 and AYC-Gx4 family manual Page 17
Transmit Mode and the keypad transmission format will remain
unchanged
4) Look on the next page for more information on keypad
transmission formats.
5) System returns to Transmit Mode.
• You will hear three beeps.
• The Program LED will turn off
• The Transmit LED will turn red
Note:
• Only one keypad transmission format can be active at any
one time.
• When using the keypad transmission format "1 to 8 keys
BCD, Clock & Data" (Option 8) an additional input is
required to specify the number of keys in the PIN code.
Keypad Transmission Format Option Number
See the table below to determine the Option Number for the
Keypad Transmission Format you wish to select
Keypad Transmission Format
Option Number
Single Key, 6-Bit Wiegand (Rosslare Format)
1*
Single Key, 6-Bit Wiegand with Nibble + Parity Bits 2
Single Key, 8-Bit Wiegand, Nibbles Complemented
3
4 Keys Binary + Facility Code, 26-Bit Wiegand
4
1 to 5 Keys + Facility Code, 26-Bit Wiegand
5
6 Keys BCD and Parity Bits, 26-Bit Wiegand
6
Single Key, 3x4 Matrix Keypad
7
1 to 8 Keys BCD, Clock & Data Single Key
8
* Option 1 is the default factory setting.
More information on each of the different keypad transmission
formats is available below and on the following pages.
Mode/Transmit
Door/Program
Red
