Rosslare AYC-G64 User Manual

Reader Functionality
AYC-Fx4 and AYC-Gx4 family manual Page 24
seconds, the keypad will clear the card buffer and the PIN code
entry buffer, generate a medium length beep and be ready to
receive a new card.
The keypad PIN code can be one to five digits long in the range
of 0 to 99,999. When entering a keypad PIN code, the # key must
be pressed to signify the end of the PIN entry. When pressing the #
key press, the data is sent by the Wiegand data lines. If the * key is
pressed, the keypad will clear the card buffer and the PIN code
entry buffer, generate a medium length beep and is ready to
receive a new card.
AYC-Fx4/AYC-Gx4 output card data in 26-Bit Wiegand with the
following keypad data in 26-Bit Wiegand format.
Card Data: (EP) AAAA AAAA AAAA BBBB BBBB BBBB (OP)
Where: EP =Even parity for first 12 A bits.
OP =Odd parity for last B 12 bits.
PIN Data: (EP) 0000 AAAA BBBB CCCC DDDD EEEE (OP)
Where:
A = The first key entered.
D = Fourth key entered
B = Second key entered
E = Fifth key entered.
C = Third key entered
EP =Even parity for first 12 bits.
OP =Odd parity for last 12 bits.
If the PIN code is less than 5 digits, all the most significant nibbles
are filled with 0.
Example: (EP) 0000 0000 0000 0000 AAAA BBBB (OP)
Where:
A = The first key entered. B =Second key entered
EP =Even parity for first 12 bits.
OP =Odd parity for last 12 bits.
5.2.3. Changing the Programming Code
1) Enter Programming Mode.
2) Press “3” to enter Menu 3.
3
Mode/Transmit
Door/Program
Green
