Controller Functionality
AYC-Fx4 and AYC-Gx4 family manual Page 40
6.9.11. Quick Reference Guide for Auxiliary Mode Setting
Auxiliary
Mode
Auxiliary Input
Function
Auxiliary Output
Activated by
Auxiliary
Relay
Auxiliary Settings
(in seconds)
0 AUX REX Valid code or AUX REX N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
1 Normal/Secure switch
Valid code N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
2
Normal/Secure switch
Star button (

)
N.O.
01 to 99 Aux. relay release time
00 Aux. relay toggle
3 Normal/Secure switch
Tamper event N.C. 01 to 99 Aux. relay release time
00 Aux. relay tamper activated
4
Normal/Secure switch
Direct shunt
N.O.
01 to 99 Shunt time
5
Door Monitor
Shunt
N.C.
01 to 99 Maximum shunt time
6
Door Monitor
Forced door
N.C.
01 to 99 Forced delay
7
Door Monitor
Door ajar
N.C.
01 to 99 Ajar delay
8
LED control – Green
Valid code
N.O.
01 to 99 Aux. relay release time
00 Aux. relay toggle
9 LED control - Red Valid code N.O. 01 to 99 Aux. relay release time
00 Aux. relay toggle
