Rotabroach COMMANDO40/3 - PARTS LIST

Commando 40 Manual Original instructions June 2014
14
13) PARTS LIST
Item
Rotabroach P/N
Description
Qty/pcs
Item
Rotabroach P/N
Description
Qty/pcs
1
RD4347
M5×16 Cross Sunk Screw
2
13
RD33148
Spacer For Bearing Bracket
1
2
RD45607
M5 Lock Washer
2
14
RD23626/RD23625
Magnet Base Assembly
230v/110v
1
3
RD4103
M3×6 Cross Panhead Screw
1
15
RD4078
M8 Flat Washer
2
4
RD33647
Guard Bracket
1
16
RD4079
M8 Elastic Washer
2
5
RD4077
M4×8 Cross Panhead Screw
7
17
RD43619
M8×88 Hex Head Tap Bolt
2
6
RD33640
Guard
1
18
RD33632
Housing Assembly
1
7
RD4066
M8×8 Lock Screw
2
19
RD4312
M6×12 Lock Screw
4
8
RD23114/RD23115
Motor Assembly 110V/230V
1
20
RD45622
Pin 3×8
2
8.1
RD4056
Circlip 19-Hole
1
21
RD4313
Sleeve
2
8.2
RA354
Button
1
22
RD3303
Pinion Shaft Sleeve
1
8.3
RA3118
Spring
1
23
RD4096
M6 Elastic Washer
5
8.4
RD33155
Arbor
1
24
RD4098
M6×20 Socket Cap Screw
5
8.5
RD4066
Screw M8×8
2
25
RD4077
M4×6 Cross Panhead Screw
4
8.6
RD33156
Arbor Spindle
1
26
RD4302
Warning Label
1
8.7
RD43304
Oil Seal
2
27
RD4325
M5×16 Socket Cap Screw
2
8.8
RD33602
Gearbox
1
28
RD4092
M5 Elastic Washer
6
8.9
RD43305
Ball Bearing 6003
2
29
RD33338
Dirigible Wheel
1
8.10
RD43306
Circlip 35-Hole
1
30
RD4414
M4×10 Socket Cap Screw
2
8.11
RD43607
Lock Assembly
1
31
RD33320
Clamp Assembly
1
8.12
RD43626
Dishing Washer
1
32
RD4269
M6×25 Socket Cap Screw
1
8.13
RD43608
Washer
1
33
RD45605
Coolant Elbow
1
8.14
RD33603
Brass Washer
2
34
RD23603
Cooling Bottle Assembly
1
8.15
RD33604
Big Gear
1
35
RD33644
Gib Support Strip
1
8.16
RD43609
Gear Bushing
1
36
RD33645
Adjustable Gib Strip
1
8.17
RD33606
Internal Tooth Bushing
1
37
RD33630
Slide
1
8.18
RD43310
Circlip 14-Shaft
1
38
RD33600
Rack
1
8.19
RM17134
Ball Bearing 608
3
39
RD33646
Fixed Gib Strip
1
8.20
RD33607
Gear-Shaft
1
40
RD4091
M5×25 Socket Cap Screw
4
8.21
RD33608
Small Gear
1
41
RD4210
Coil Pipe Clamp
1
8.22
RD33609
Inner Gearplate
1
43
RD43357
Spring Washer M4
2
8.23
RD45614
Bearing Pin
1
44
RD43600
Connector
1
8.24
RD45522
Ball Bearing 6001
1
45
RD23110/RD23109
Control Panel Assembly
230v/110v 230v/110v
1
8.25
RD33623/RD33610
Armature 230V/110V
1
46
RD25620/RD25619
Cable Assembly 230v/110v
1
8.26
RD43603
Ball Bearing 629
1
47
RD33643
Capstan Spindle
1
8.27
RD35639
Inductor
1
48
RD33642
Capstan Arm
3
8.28
RD33611
Fan Baffle
1
49
RD43091
Capstan Ball
3
8.29
RD43625
Tapping Screw St4.8×60
2
50
RD33178
Brand Label
1
8.30
RD33633/
RD33631
Field Leadwire Sa 230v/110v
1
51
RD45621
M4×22 Cross Panhead Screw
1
8.31
RDB3069
Bearing Sleeve
1
52
RD4069
M4 External Tooth Washer
1
8.32
RD33186
Commando 40 Motor Housing
1
53
RD45604
Earth Tag
1
8.33
RD43624
Screw SA M5×42
4
54
RD4070
M4 Flat Washer
2
8.34
RD33616
Brush Cover
2
55
RD4068
M4 Hexagon Nut
2
8.35
RD35612
Brush
2
56
RD33341
Flat Key
1
8.36
RD33614
Brush Holder
2
57
RD4095
M6 Flat Washer
4
8.37
RD23643/RD23630
Speed Controller 230v/110v
1
58
RD45606
Protecting Switch
1
8.38
RD45610
Tapping Screw St3.9×16
2
59
RD43117
Cable Gland
1
8.39
RD35617
Terminal
2
60
RD43093
M4×14 Cross Panhead Screw
2
8.40
RD45613
Screw M3×6
4
61
RD33145
Depth Gauge
1
8.41
RD35619
Protector
1
62
RD33146
Label-Plate Rivet
2
8.42
RD45612
Tapping Screw St3.9×12
4
63
RD33144
Handle Sheath
1
8.43
RD23623
Motor Cable Assembly
1
64
RD4329
Safety Strip
1
8.45
RD35615
End Cap
1
65
RD4088
Hexagon Spanner 4mm
1
8.46
RD43618
Tapping Screw St3.9×32
4
66
RD4152
Hexagon Spanner 3mm
1
9
RD33070
Information Plate
1
67
RD33154
Drill Chuck Key
1
10
RD45624
Needle Bearing Hk354216
1
68
RD43099
13mm Drill Chuck
1
11
RD45620
Spring Plunger
2
69
RD33153
Drill Chuck Adaptor
1
