Rotabroach ELEMENT 50 LOW PROFILE 1 - Specification

Element 50 Low Profile Manual Original instructions 2019
6
4)SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 50mm dia. x 50mm deep
Arbor bore = 19.05mm (3/4") dia.
Motor Unit
Voltages
110V 50-60Hz
230V 50-60Hz
Normal full load
10 A
1200 W
6 A
1200 W
Electro Magnet
0.53 A
56W
0.28 A
61W
Size
192mm long
82 mm wide
Holding Force at 20°C with 25mm
minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine MUST be used.
10000N
Overall Dimensions
Height - minimum
179mm
Width (including Capstan fitting)
100mm
Length Overall (including Guard)
334mm
Nett Weight
11 kgs
ELEMENT 50 LOW
PROFILE 1
ELEMENT 50 LOW
PROFILE 3
Vibration total values (triax vector sum) in accordance with
EN62841-1:
Vibration emission value
a W= 5,782 m/s2
Uncertainty(K):1.5m/s²
Vibration emission value
a W= 5,735 m/s2
Uncertainty(K):1.5m/s²
Level of sound pressure in accordance with EN62841-1:
LpA: 85 dB(A)
LwA: 98 dB(A)
uncertainty(K)：3dB(A)
LpA: 84 dB(A)
LwA: 97 dB(A)
uncertainty(K)：3dB(A)
Vibration and Noise
The declared vibration total value(s) and the declared noise emission value(s) have been measured in accordance with a standard
test method and maybe used for comparing one tool with another;
The declared vibration total value(s) and declared noise emission values(s) may also be used in a preliminary assessment of
exposure.
The vibration and noise emissions during actual use of the power tool can differ from the declared total value depending on the ways
in which the tool is used and especially what kind of workpiece is being processed
The need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of
use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in
addition to the trigger time).
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when operating the
machine.
These tools are UK designed and manufactured with globally sourced components and conform to the requirements of
EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
