No
Function
Wire Colour
A
Motor 'Reverse' Switch 0V
White
B
Motor 'Reverse' Switch +5V
White
C
Motor 'Forward' Switch 0V
White
D
Motor 'Forward' Switch +5V
White
E
Magnet Switch 0V
White
F
Magnet Switch +5V
White
G
Magnet 'ON' LED +5V
White + Green
H
Magnet 'ON' LED +5V
White + Red
I
Magnet 'ON' LED 0V
White + Brown
J
Power 'ON' LED 0V
White + Black
K
Power 'ON' LED +5V
White + Brown
L
Motor 'Reverse' LED OV (BLUE)
White
M
Motor 'Reverse' LED +12V (BLUE)
White
N
Motor 'Forward' LED 0V (Green)
White
O
Motor 'Forward' LED +12V (Green)
White
