Rotabroach Element 75 - Parts List

Element 75 Manual Original Instructions Aug 2016
16
Item#
Rotabroach P/N
Description
Qty/pcs
1
RDA4201
Screw M4×14 Button Head
2
2
RDC4004
Screw M4×8 Button Head
1
3
RDD4014
Element 75 Guard
1
4
RDD4015
Slide channel
1
5
RDA4201
Screw M5×12 CSK HD
2
6
RD45607
M5 CSK Washer
2
7
RDD4017
Guard support
1
9
RDA4029
Screw M6×16 CAP HD
3
10
RDC4104
Spring washer
3
11
RDD4081
Rack
1
12
RDC4065
Cable chain attachment
1
13
RDA4021
Screw M4×8 Button Head
10
14
RDA4205
M3 Nut
2
15
RDA4204
Screw M3×8 CSK HD
2
16
RDC4066
Screw M5×12 Button Head
1
17
RDD4084
Chain
1
18
RDD4085
Screw M8×22 CSK HD
6
19
RDD4086
Slide
1
20
RDD4087
Screw M6×22 CAP HD
1
21
RDD4088
Guide bar
2
22
RDC4059
Screw M5×16 CAP HD
10
23
RDC4056
Grub Screw M6×15
5
24
RDC4057
M6 nut
5
25
RDD4092
Bush
2
26
RDD4093
Capstan Washer
2
27
RDD4094
Circlip
2
28
RDD4095
Right side panel
1
29
RDC4068
Screw M4×16 CSK HD
2
30
RDA4005
Cable bush
1
31
RDD4097
Main housing
1
32
RDC4055
Screw M8×25 CAP HD
2
33
RD4079
Spring washer
4
34
RDD4100
Magnet-230V
1
RDD4101
Magnet-110V
1
PARTS LIST
