Rotabroach Element 75 - Page 17

Element 75 Manual Original Instructions Aug 2016
17
Item#
Rotabroach P/N
Description
Qty/pcs
35
RDA4071
Screw M4×22
2
36
RDA4070
Cable clamp
1
37
RD4068
M4 nut
4
38
RD4069
M4 Washer
1
39
RD45604
Earth label
1
40
RDD4103
Left side panel
1
41
RDD4104
Capstan arm
3
42
RDD4105
Capstan Hub
1
43
RDD4106
Intermediate gear shaft
1
44
RDD4107
Screw M5×8 CAP HD
2
45
RDD4108
Handle insert
1
46
RDA4204
Screw M4×8 CSK HD
4
47
RDC4073
Screw M8×45 CAP HD
2
48
RDC4074
Power cable-230V
1
RDD4112
Power cable-110V
1
49
RDD4113
Screw M6×15 Button Head
2
50
RDD4114
Capstan bracket
2
51
RDD4115
Bracket screw
2
52
RDD4116
Washer 6
2
53
RDD4117
Handle
1
54
RDD4118
Screw M4×12 Button Head
6
55
RDD4119
Control panel assembly-E75/3T
1
RDD4120
Control panel assembly-E75/1T
1
56
RDD4123
Coolant bottle assembly
1
57
RDC4081
Clamp (using 110V)
1
58
RDC4080
Tapping screw ST2.9×12(using 110V)
3
59
RDD4126
Chuck
1
60
CA130
Arbor assembly
1
61
RDA3105
Safety glasses
1
62
RDD4128
Arbor Shank
1
63
RDC4086
Drift
1
64
RDC4083
Safety belt
1
65
RD4152
3mm hexagonal spanner
1
66
RDC4082
stationary ring
2
67
RDD4132
Spare brush-230V
1pair
RDD4133
Spare brush-110V
68
RA3120
Pilot Pin
1
