Rotabroach Element 75 - Page 19

Element 75 Manual Original Instructions Aug 2016
19
PARTS LIST
Item#
Rotabroach P/N
Description
Qty/pcs
8
RDD4018
Motor assembly-230V
1
RDD4019
Motor assembly-110V
1
8.1
RDD4020
Circlip
1
8.2
RDD4021
Oil seal washer
1
8.3
RDD4022
Arbor spindle
1
8.4
RDD4023
Key steel
1
8.5
RDD4024
Rolling bearing 6006
1
8.6
RDD4025
Gear box
1
8.7
RD45614
Straight Pin
1
8.8
RDB4008
Spring
1
8.9
RDB3030
Gear lever
1
8.10
RDC4013
Gear lever M4 shoulder bolt
1
8.11
RD45522
Rolling bearing 6001
2
8.12
RDD4028
Helical gear
1
8.13
RDD4029
Gear
1
8.14
RDD4030
Key steel
1
8.15
RDD4031
Shaft gear
1
8.16
RDD4032
Rolling bearing 6000
2
8.17
RDD4033
Needle bearing
1
8.18
RDD4034
Sliding gear unit
1
8.19
RDD4035
Shaft gear
1
8.20
RDD4036
Key steel
1
8.21
RDD4037
Oil seal
1
8.22
RDD4038
Rolling bearing 6005
1
8.23
RDD4039
Gear
1
8.24
RDA4004
Circlip
1
8.25
RDD4040
Gear lever shaft
1
8.26
RDD4041
Oil baffle plate
1
8.27
RDD4042
Circlip
1
8.28
RDD4043
Gear plate
1
8.29
RDD4044
Circlip
1
8.30
RDD4045
Armature-230V
1
RDD4046
Armature-110V
1
8.31
RD43603
Rolling bearing 629
1
8.32
RDD4048
Bearing Sleeve
1
8.33
RDC4029
Inductor
1
8.34
RDD4050
Screw M5×16 Button Head
4
8.35
RDD4051
Tapping screw ST4.8×25
4
8.36
RDD4052
baffle plate
1
8.37
RDD4053
Tapping screw ST4.8×70
2
