Rotabroach SMARTPANTHER1 - Page 12

Issue 3 Original Version March 2012
- 12 -
Item
Part No.
Component
Quantity
Item
Part No.
Component
Quantity
1
RD23601
Guard Assembly
1
6.13
RD45604
Earth tag
1
1.1
RD33640
Guard
1
6.14
RD45606
Protection switch
1
1.2
RD4077
Panhead screw
2
6.15
RD33145
Depth Gauge
1
1.3
RD33647
Guard bracket
1
6.16
RD33146
Label plate rivet
2
1.4
RD45620
Spring plunger
1
7
RD23604
Capstan arm assembly
1
1.5
RD4347
Countersunk screw
2
7.1
RD33642
Capstan arm
3
1.6
RD45607
Washer
2
7.2
RD43091
Capstan Knob
3
1.7
RD4103
M3 Socket head screw
1
8
RD23610
Capstan assembly
1
2
RD23605
Bearing bracket assembly
1
7
RD23604
Capstan arm assembly
1
2.1
RD33635
Bearing bracket
1
8.2
RD4313
Nyliner bearing
2
2.2
RD45624
Arbor bearing
1
8.3
RD3303
Pinion shaft sleeve
1
3
RD23066
Motor & Gearbox assembly(110V)
1
8.4
RD4096
M6 shakeproof washer
1
3
RD23067
Motor & Gearbox assembly(230V)
1
8.5
RD4098
M6 socket head screw
1
3.1
RD43600
Cable connector
1
8.6
RD33643
Capstan pinion shaft
1
3.2
RD4091
M5 socket head screw
4
9
RD23612
Gib strip assembly
1
3.3
RD4092
M5 Shakeproof washer
4
9.1
RD33644
Gib support strip
1
3.4
RD4066
Cutter retaining screw
2
9.2
RD33645
Adjustable gib strip
1
3.5
RD45605
Coolant connector
1
9.3
RD33646
Fixed Gib strip
1
4
RD23608
Slide assembly
1
10
RD23603
Oil bottle assembly
1
4.1
RD33630
Slide
1
10.1
RD23617
Bottle and bracket assembly
1
4.2
RD33341
Key
1
10.2
RD33320
Tension plate
1
4.3
RD33600
Rack
1
10.3
RD4269
Socket head cap screw
1
4.4
RD4325
M5 socket head screw
2
11
RD23098
Control unit assembly (110V)
1
4.5
RD4092
M5 Shakeproof washer
2
11
RD23099
Control unit assembly (230V)
1
5
RD23619
Housing sub assembly
1
12
RD43093
Pan head screw
4
5.1
RD33632
Housing
1
13
RD25619
Mains cable assembly (110V)
1
5.2
RD45622
Tension pin
2
13
RD25620
Mains cable assembly (230V)
1
5.3
RD33144
Handle cover
1
14
RD23625
Magnet base assembly (110V)
1
5.4
RD43117
Mains Cable clamp
1
14
RD23626
Magnet base assembly (230V)
1
6
RD23609
Housing assembly
1
15
RD33148
Arbor bracket spacer assembly
1
5
RD23619
Housing sub assembly
1
16
RD43619
Arbor bracket bolt
2
6.2
RD45621
M4 screw
1
17
RD4079
Shakeproof washer
2
6.3
RD4069
M4 Shakeproof washer
2
18
RD4078
Plain washer
2
6.4
RD4070
M4 washer
2
19
RD4098
socket set screw
4
6.5
RD4068
M4 hexagon nut
2
20
RD4096
Shakeproof washer
4
6.6
RD4077
M4 pan head screw
4
21
RD4095
Flat washer M6
4
6.7
RD43083
Logo plate
1
22
RD33070
Speed Label
1
6.8
RD4302
information plate
1
23
RD4329
Safety Strap
1
6.9
RD4312
M6 tuflock screw
1
24
RD4088
4mm Allen Key
1
6.1
RD33338
Fixed ratchet wheel
1
25
RD43099
13mm Drill Chuck
1
6.11
RD4414
M4 sockethead screw
1
26
RD33153
Drill Chuck adaptor
1
6.12
RD4210
Cable clip
1
27
RD33154
Drill Chuck Key
1
