Rotabroach SMARTPANTHER1 - Page 14

Issue 3 Original Version March 2012
- 14 -
Component parts of motor and gearbox RD23661 (110v) & RD23663 (230v)
Item
Part No.
Component
Qty
Item
Part No.
Component
Qty
1
RD23651
Motor assembly (110v)
1
4
RD23616
Motor housing assembly
1
1
RD23653
Motor assembly (230v)
1
4.1
RD33613
Motor housing
1
2
RD23631
Armature assembly (110v)
1
4.2
RD33614
Brush holder
2
2
RD23633
Armature assembly (230v)
1
5
RD23614
Gearbox housing assembly
1
3
RD23671
Field coil & motor housing assembly (110v)
1
5.1
RD33602
Gearbox
1
3
RD23673
Field coil & motor housing assembly (230v)
1
5.2
RD43304
Seal
2
1.1
RD43624
Screw
4
5.3
RD43305
Bearing
2
1.2
RD33611
Fan guide
1
5.4
RD43306
Circlip
1
2
RD23631
Armature assembly (110v)
1
6
RD23615
Inner gearplate assembly
1
2
RD23633
Armature assembly (230v)
1
6.1
RD33609
Inner gearplate
1
2.1
RD45522
Bearing
1
6.2
RM17134
Bearing
1
2.2
RD33610
Armature 110v
1
6.3
RD45614
Bearing pin
1
2.2
RD33623
Armature 230v
1
7
RD23607
Clutch assembly
1
2.3
RD43603
Bearing
1
7.1
RD43607
Locknut
1
2.4
RD35639
Speed sensor
1
7.2
RD43608
Washer
1
3
RD23671
Field coil & motor housing assembly (110v)
1
7.3
RD33603
Brass washer
1
3
RD23673
Field coil & motor housing assembly (230v)
1
7.4
RD33604
Gear
1
4
RD23616
Motor housing assembly
1
7.5
RD43609
Clutch bush
1
3.1
RD33631
Field coil (110v)
1
7.6
RD43626
Dish washer
1
3.1
RD33633
Field coil (230v)
1
7.7
RD33606
Clutch base
1
3.2
RD43625
Screw
2
8
RD23319
Gearbox assembly
1
3.3
RD23623
Motor cable assembly
1
5
RD23614
Gearbox housing assembly
1
3.4
RD35612
Carbon brush
2
6
RD23615
Inner gear plate assembly
1
3.5
RD33616
Brush cap
2
7
RD23607
Clutch assembly
1
3.6
RD23630
Speed controller assembly (110v)
1
8.1
RD33156
Arbor spindle
1
3.6
RD23643
Speed controller assembly (230v)
1
8.2
RD33155
Arbor
1
3.7
RD45610
Screw
2
8.3
RM17134
Bearing
1
3.8
RD35615
End cap
1
8.4
RD33607
Interpinion shaft
1
3.9
RD43618
Screw
4
8.5
RD33608
Gear
1
3.10
RD35617
Terminal
2
8.6
RD43310
Circlip
1
3.11
RD45613
Screw
4
9
RA3118
Spring
1
3.12
RD35619
Terminal cover plate
1
10
RA354
Button
1
3.13
RD45612
Screw
4
11
RD4056
Circlip
1
