Rotek 800A - 5.6 Programming Examples

44
Table 5-3
Transmission of Deviation Data
Byte
Sequence Description ASCII Character
1 Polarity +, -
2 MSD 1, 0
3 2nd digit 0-9
4 3rd digit 0-9
5 Exponent Symbol E
6 Exponent polarity -
7 Exponent 4=.1%, 5=1%
8 Carriage Return CR
9 Line feed with EOI LF
Table 5-4
Transmission of Energy Data
(811A/811AE only)
Byte
Sequence Description ASCII Character
1 Blank
2 MSD 1-9
3 2nd digit 0-9
4 3rd digit 0-9
5 4th digit 0-9
6 5th digit 0-9
7 Exponent Symbol E
8 Exponent Polarity +,-
9 Exponent 1-3
10 Carriage return CR
11 Line Feed with EOI LF
