Rotek 800A - 6 Parts List; List of Recommended Spare Parts

49
6. Parts List
6.1 List of Recommended Spare Parts
Description Rotek P/N Mfg. Code Mfg. P/N Quantity
Integrated Circuits Linear
Voltage Comparator ICLCOMPX02CP 24355 CMP02CP 1
Op Amp ICLOALNX07CP 24355 OP07CP 4
Op Amp ICLOALNX27GZ 24355 OP27GZ 2
Voltage Comparator ICLCOMPLM311 27014 LM311N 1
Op Amp ICLOAAD741LN 24355 AD741LN 1
Mod/Demod ICLMODXX1496 04713 LM1496P 1
Analog Switch ICLASSP201GP 24355 SW201GP 4
Blowers
Blower FANHIVLBT2A1 82877 BT2A1 1
Converters
12 Bit D/A W/BCD ICDDAAD562KD 24355 AD562KD/BCD 1
Regulators
+5V 3 Amp REG05VPOS03A 27014 LM323K 1
-15V 1 Amp REG15VNEG01A 27014 UA7915KC 1
+15V 1 Amp REG15VPOS01A 27014 UA7815KC 1
Diodes
Signal DIOCRN914XXX 27014 1N914 5
Rectifier DIOCR4002XXX 04713 1N4002 2
Hi Speed DIOCR2800XXX 28480 5082-2800 2
Fuses
½ Amp MB FUSE0.50M032 75915 311.50 5
¼ Amp SB FUSE0.25S250 75915 313.250 5
4 Amp SB FUSE4.00S250 75915 326004 10
15 Amp MB FUSE15.0M032 75915 311015 10
Integrated Circuits, Digitals
Gate ICDNANDXLS00 27014 DM74LS00 4
Hex Inverter ICDINVXXLS04 02195 SN74LS04 4
Triple 3 Input ICDNANDXLS10 02195 SN74LS10 1
Quad 2 Input Gate ICDORXXXLS32 02195 SN74LS32 1
Dual J-K Flip Flop ICDJKFFXLS73 02195 SN74LS73 1
4 Bit Full Adder ICDADDERLS83 02195 SN74LS83 1
4 Bit Bin. Counter ICDCOUNTLS93 02195 SN74LS93 1
Multiplexer ICDMPXRXX150 27014 DM74150 1
Decoder ICDDECXLS154 02195 SN74LS154 1
DEC-BCD Encoder ICDENCDLS147 02195 SN74LS147 1
Multivibrator ICDMULTLS123 27014 DM74LS123 1
Multiplexer ICDMPXRLS157 02195 SN74LS157 1
3 State D-type F/F ICDDFFXLS374 27014 DM74LS374 4
Driver High Voltage ICDDRVR75468 02195 SN75468 1
