 IDU-Console 4 
3. Part names
Drain hose
Refrigerant connecting
pipe
Display panel
Air inlet (with air lter in it)
Air ow louver (at air outlet)
Air ow louver (at air outlet)
4. Service Place
≥100mm
≥100mm
≥100mm
≥1000mm
