 Indoor Unit Disassembly 6 
1.3 Display Board
Procedure Illustration
1) Open the install cover assembly(with
display board) (see CJ_MCD1_008)
2) Remove 1 screw of display window
board. (see CJ_MCD1_009)
CJ_MCD1_008
CJ_MCD1_009
Note: This section is for reference only. Actual unit appearance may vary.
