 Indoor Unit Disassembly 2 
1. Indoor Unit Disassembly
1.1 Front Panel
Procedure Illustration
1) Push one side of the grille clamp. (see
CJ_MCD1_001)
2) Remove one screw then push two
grille clamps to remove the air inlet
grille assembly.(see CJ_MCD1_002)
CJ_MCD1_001
CJ_MCD1_002
Note: This section is for reference only. Actual unit appearance may vary.
