User Manual - 3/32
I. SAFETY
Roth Touchline® SL Control system must always be installed by a qualied person. The controller must always be mounted on a wall or in a cabi-
net in a secure way.
WARNING
Risk of fatal electric shock from touching live connections. Before working on the controller switch o the power supply and
prevent it from being accidentally switched on.
NOTE
Incorrect connection of cables may lead to controller damage.
1. Cover (it must be removed to connect the devices to the controller)
2. Display
3. Antenna – for wireless communication (hidden inside the cabinet)
4. Control buttons
!
!
Touchline® SL Controller 8 ch master
1 2 4
3
