BASE TABLE & RISER ASSEMBLY
PLATE NO. – 1
S. NO. DESCRIPTION QTY/M/C
1 COVER PAN 1
2 RISER 1
3 SCREW 4
4 WASHER 4
5 STOP PLATE 2
6 PLATE 1
7 VACCUM GAUGE 2.5” STD-B X ¼ NPT 1
8 N-22-SW (9301) 1
9 SV-3-M5 (6817) 1
10 GSS-6 (153158) 1
11 TOOL CABINET 1
12 TOOL TRAY 4
13 MOUNTING BRACKET 1
14 KNOB 1
15 CLAMP PIN 1
16 CLAMP LEVER 1
17 TABLE 1
18 WASHER 4
19 SCREW 4
20 PLAIN WASHER 11
21 LOCK WASHER 11
22 HEX. SCREW 3
23 HEX SCREW 7
24 CABINET ASSY 1
25 HEX SCREW 4
26 LEVELING BOLT 6
27 HEX NUT 6
28 PAD 6
29 HANDLE 2
30 MEGNET BLOCK 2
31 SPRING 2
32 ROD 1
33 FRAME WELDED 1
34 SCREW 2
35 FOOT SWITCH MTG. BRACKET 1
36 SCREW 2
37 FOOT SWITCH ASSY 1
38 NUT 2
