Rottler SGF8 - Page 29

Machine Parts 11-5 SG8 Manual
TRANSMISSION ASSEMBLY
PLATE NO. - 4
S. NO. DESCRIPTION QTY/M/C
1 SENSOR WHEEL 1
2 EXT. CIRCLIP 1
3 BALL BEARING 2
4 ALLEN SCR. ¼” BSW X ¾” 6
5 BEARING HOUSING 1
6 PLATE 1
7 ALLEN SCREW 10-32 X 5/8” LONG 4
8 DRIVE PULLEY 1
9 FLANGE 1
10 IDLER PULLEY 2
11 ALLEN SCREW ¼” NF X 1.250” 1
12 1/4” WASHER 3
13 BEARING 2
14 IDLER HUB 1
15 HEX NUT 1/4”-20 1
16 MOTOR CONTROL SUPPORT 1
17 V-BELT (COUNTER SHAFT) 1
18 PULLEY 1
19 GRUB SCR. ¼” -20 X 3/8” CUP PT. 3
20 MOTOR DC 1HP (CDP 3445) 1
21 ALLEN SCR. 3/8” BSW X 1” LONG 4
22 3/8” WASHER 4
23 PULLEY 1
24 ALLEN SCREW 1/4” X 2” LONG 1
25 IDLER HUB 1
26 HEX NUT 1/4” -20 1
27 V-BELT (DRIVE) 1
28 SHAFT 1
29 WOODRUF KEY 3/16” X 3/4” LONG 1
30 PULLEY 1
31 EXT. CIRCLIP 2
32 BEARING 2
33 INT. CIRCLIP 2
34 HEX SCREW 1/4” BSW X 3/4" LONG 2
35 1/4” WASHER 2
36 ALLEN SCREW 4
37 COVER SUPPORT 4
38 COVER SUPPORT 2
39 COVER SUPPORT 2
40 SPACER ( NOT SHOWN) 4
41 SENSOR SWITCH MTG. BKT. (NOT SHOWN) 1
42 FLANGE 1
