Roundup VCT-1000 - Replacement Parts (Continued); Detailed Parts List

VERTICAL CONTACT TOASTER
22 P/N 1010807 Rev. I 06/12
A.J. Antunes & Co.
1 0011266 Conveyor Belt (Incl. Items Below) 2
0800204 1/2” Pitch Link, Small 2
0800121 3/4” Pitch Link, Large 38
2 2150117 Idler Shaft 2
3 0011609 Conveyor Cover Assy. (Incl. #95) 2
4 0010475 Tensioner Assy. (Incl. #40, 76, 85) 4
5 0800332 Rod, Conveyor Cover 4
6 7000207 Sprocket (Incl. #65) 8
7 7000199* SpacerKit 2
8 0011444 Control Cover 1
9 2150118 DriveShaft 2
10 0700452 Power Cord/Plug, NEMA 6-20P 1
0700463 Power Cord/Plug, NEMA 5-15P 1
0700437 Power Cord/Plug, IEC-309 1
0700453 Power Cord/Plug, CEE 7/7 1
11 4030355 Thermostat, 600°F 1
12 7000296 Ball Bearing (Pack of 2) 1
16 7000167 Bearing&RetainerKit 6
16A 7000224 Bearing&RetainerKit(Incl.Sixof#16) 1
17 2150181 DriveSprocket 2
 2150109 DriveSprocket(Mfg.No.9210705only) 2
18 2150187 DriveChain 1
 2150215 DriveChain(forMfg.#9210714&720) 1
19 0011299 Idler Sprocket & Bearing 1
20 0011300 Bracket, Idler Sprocket 1
(Incl. #50, 57, 61, 19, & 87)
21 0503589 Bracket, Motor Mounting 1
22 7000240 DriveMotorKit230V(Incl.#58) 1
 7000282 DriveMotorKit120V(Incl.#58) 1
 7000271 DriveMotorKit230V 1
(for Mfg. #9210714 & 720)
0012112 Gearmotor Assy 230V 3 RPM 1
(for Mfg. #9210705)
23 2150199 Sprocket, Motor (Mfg. #9210700, 702, 2
706, & 708)
2150211 Sprocket, Motor (Mfg. #9210704, 710 2
& 9210712)
2150112 Sprocket, Motor (for Mfg #9210714 & 720) 2
2150173 Sprocket, Motor (Mfg. No. 9210716 & 722) 2
24 4010245 Rocker Switch, On/Off 1
25 4060355 Terminal Block 1
26 0503495 Retainer, Tension Bracket, RH 2
27 0503507 Retainer, Tension Bracket, LH 2
28 4060229 Indicator Light, Amber (250V) 1
4060323 Indicator Light, Amber (125V) 1
29 0011374 Spring Tensioner Assy. 2
30 0503496 Tensioner Bracket, Right 2
31 0503497 Tensioner Bracket, Left 2
32 1000899 Label, Control 1
33 10P1047* Label,Dial(Packof10) 1
34 2100253 Knob,Cam 2
35 0011445 Cover, End Housing 1
36 2100133 Knob,ThermostatControl 1
37 0021170 Weldment, End Housing 1
38 7000249 Release Sheet (Pack of 3) -
7000250 Release Sheet (Pack of 10) -
39 0021194 Weldment, Control Housing 1
40 7000121 SlideRailKit(Incl.TwoSlideRails 2
for Tensioners)
41 0021207 Conveyor Cam 2
42 7000176 ThermocoupleRetainerKit 2
43 4030332 High Limit Control 1
44 0400251 Strain Relief 1
0400315 Strain Relief (Mfg # 9210704 only) 1
45 0400138 Locknut, 1/2” 1
46 0503590 Bracket, Motor 1
48 0503385 Bun Chute 1
50 331P101* Nut, Hex, 5/16 x 18” 1
51 7000200 Platen, 208V 1
7000229 Platen, 120V 1
7000289 Platen, 230V (Mfg. #9210712) 1
52 2100266 Tape 2
53 4010107 Interlock Switch 1
57 0503608 Cover Plate 2
58 4000170 Fan Blade, Motor 1
59 2100256 Tape, Hi-Temp 8
61 212P118* Flat Washer, 5/16” 1
62 0500464 Retainer, Bearing 1
64 0011528 Heat Shield Assy. 1
65 325P163 Setscrew, 1/4-28 x 5/16” 8
66 100P864* Label, Caution Hot 1
67 308P154* Screw, #10-32 x 3/8” 2
68 306P104* Screw, #6-32 x 1/4” 8
69 406P107* Cable Tie 1
70 308P143* Nut,#8-32,“KEPS” 6
71 310P103* Screw, #10-32 x 1/4” 4
72 310P140* Washer, #10 6
73 308P101* Nut, #8-32 3
74 306P101* Nut, Hex, #6-32 2
75 306P123* Screw, #6-32 x 7/8” 2
76 308P145* Nut, Hex Acorn, #8-32 14
77 100P900* Label, Service 1
78 325P104* Washer, 1/4” 4
79 325P109* Screw, 1/4-20 x 1/2” 4
80 308P124* Screw, 1-Way, #8-32 x 1/2” 1
81 210P230 Bumper, Recess Leg, 1” 4
82 310P136* Screw, #10-32 x 1-1/4” 4
83 308P133* Screw, #8-32 x 1/4” 12
84 308P183* Screw, Hex Head, #8-32 x 3/8” 4
85 308P181* Screw, Flat Hd., #8-32 x 3/8” 4
86 218P145* Cover, Leg, Bumper 4
87 331P103* Shoulder Bolt, 5/16”-18 1
88 306P105* Screw, #6-32 x 1/2” 1
89 0503455 Tension Spring, Inner 4
90 2100259 Slide Bar 4
91 0011549 Bun Feeder 1
92 7000192 Belt Wrap (optional for Mfg. No. 9210716 1
722 & 727)
93 0011491 Conveyor Cover Assy. (9210706, 708, 1
710, 716, 722, & 727) (Incl. #94)
94 7000186 RollerTensionerKit(Packof3) 1
95 0011374 Spring Tensioner (Incl. #52) 2
* Only available in packages of 10.
Item PartNo. Description Qty. Item PartNo. Description Qty.
REPLACEMENT PARTS (continued)
