Roundup VCT-1000 - Optional Parts

23P/N 1010807 Rev. I 06/12
VERTICAL CONTACT TOASTER
A.J. Antunes & Co.
THICKNESS
THICKNESS












1 =
1/2"
(12.7mm)
5/8"
2 =
(15.9mm)
11/16"
3 =
(17.5mm)
3/4"
4 =
(19.1mm)
13/16"
5 =
(20.6mm)
7/8"
6 =
(22.2mm)
OPTIONAL PARTS
Mechanical Butter Wheel Kit (P/N 7000298) Requires Professional Installation.
1 7000298 ButterWheelKit(IncludesItemsBelow)
a 0011552 End Housing Cover Assy. 1
b 0011573 Idler Shaft Assembly 1
c 0021320 Roller Weldment 1
d 0500464 Retainer, Bearing 1
e 0503987 Pan, Butter 1
f 1001047 Label,DialCompression 1
g 1010773 Instruction Sheet (not shown) 1
h 2120107 Spacer, Aluminum 1
i 3080162 #8-32 x 1-1/4 Screw (not shown) 1
Item PartNo. Description Qty.
a
b
c
d
e
f
h
i
1 7000238 ButterWheelKit(IncludesItemsBelow)
a 0020205 Butter Roller Weldment 1
b 0021232 Butter Tray Weldment 1
Item PartNo. Description Qty.
Mechanical Butter Wheel Kit
(model 7000238)
b
a
