2. SPECIFICATIONS
2-1 General
Main supply
: 100V/120V/220V/230V±10% 50/60Hz (Switch selectable).
Rating, dimension and weight : see Table 2-1
Operation mode : Single or Tracking (Series or Parallel) operation (two units).
Operation Temperature & Humidity : 0ºC to 40ºC, <80%
Storage Temperature & Humidity : -10ºC to 70ºC, <70%
Maximum Altitude : 2000m
Installation Category : II
Pollution Degree : 2
Product Designed for Indoor use only
Accessories : Fuse……………………………………………………………..1
: Test lead GTL-105 (current <4A)…………………..……….….1
GTL-104 (4A∗ current∗10A)
: Operation Manual………………………………………..……...1
Table 2-1
Max. Rating Input Rating FUSE Type and Rating Dimensions Weight
MODEL Volts (V) Amps (A) Watts VA 100V/120V 220V/230V (kg)
IPS 303A 30 3 160 200 T 2.5A 250V T 1.6A 250V 5.0
IPS 601A 60 1 120 150 T 2A 250V T 1.6A 250V
128 (W)
145 (H)
285 (D)
4.0
