Rsrteng IPC-9800ADHS Plus+ - Operation; Installing the Battery

SECURITY CAMERA User Manual
WWW.RSRTENG.COM Page.7.
30
TDR cable test interface (Optional)
31
HDMI output interface
32
Micro SD card slot,(comes with 8GB, supports up to 32GB)
33
UTP cable port: UTP cable tester port/ Cable tracer port
34
PSE power sourcing equipment. Tests PoE voltage/LAN test port
35
PoE power supply output or LAN test port (Using test PoE or non-PoE IP camera)
36
Microphone
37
USB 5V 2A power output, transmit data.
38
DC 12V 2A charging interface.
39
DC 24V 2A output
40
Audio input/Audio output and earphone interface.
3. Operation
3.1 Installing the Battery
The tester has a built-in lithium-ion polymer rechargeable battery. For safety, the battery should be
insulated during transportation. Before using the instrument, remove the battery insulation.
Normally, there is no need to insulate the battery during normal use, and the tester can be turned on
or off by pressing button continuously.
Notice: Please use the original adaptor and connected cable of the device!
When the battery icon is full or the charge indicator turns off automatically, indicate the battery
charging is completed.
Notice: When the Charge Indicator turns off, the battery is approximately 90% charged.
The charging time can be extended for about 1 hour and the charging time within 12 hours will not
damage the battery.
