4.3 Optical power meter specifications
Measure Range(dBm)
-70～+10dBm
Wavelength(nm)
850nm,1300nm,1310nm,1490nm,1550nm,1625nm
Detector
InGaAs
Uncertainly
＜±3%dB(-10dBm,22℃)
＜±5%dB(full range,22℃)
Display Resolution
Linear:0.1% ; Nonlinear:0.01dBm
Operating Temperature(℃)
-10～+50
Storage Temperature (℃)
-20～+70
Connector type
FC/PC
4.4 Visual fault locator specifications
Laser type
LD
Wavelength Calibration
650nm
Output power
5mW（Optional 10mW,20mW）
Modulation mode
CW/1Hz/2Hz
Measurement Range
5KM（Optional 10-20KM）
Connector
FC/PC exchangeable
Working Temperature
－10℃～+50℃
Operating Temperature
-20℃～+70℃
The data above is only for reference and any change of them will not be informed in advance. For more
detailed technical inquiries, please feel free to call the Technical Department of our company.
