Chapter 2. Introduction
5
RELAYSIRPWR
123
+ 12V DC
GROUND
SIGNAL IN HIGH OUT
CONTACT B CONTACT A
CONTACT A CONTACT A CONTACT B CONTACT B
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6
+ + + + + +
IR Output Level
POWER EXPANSION
Model RP-6
Remote Control Processor
STATUS
To Source Equipment,
Surround Processors,
Lighting Systems, Etc.
Each IR output can drive up
to four emitters directly.
(more than four emitters requires
an amplified connecting block)
CM-232 Communication Module
Voltage
IR Emitter
Source equipment
with a switched outlet
Video
IR Emitter
Video equipment with
Composite output
Single or Dual Emitters
Xantech® or compatible
Connecting Block
Signal Input
Emitters
RP-6
Power
Supply
*
*
*
*
Optional Accessories sold separately
Direct to Back Panel IR Port
CM-232
SPS-1
VPS-1
Wall Mount
Power
Supply
RM-433
RF or IR Receivers *
SIGNAL
