Appendix A. Mounting Hole Pattern
19
Appendix A. Mounting Hole Pattern
RELAYSIRPWR
123
+ 12V DC
GROUND
SIGNAL IN
HIGH OUT
CONTACT B
CONTACT A
CONTACT A
CONTACT A
CONTACT B
CONTACT B
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6
+ + + + + +
IR Output Level
POWER EXPANSION
Model RP-6
Remote Control Processor
STATUS
4-3/8 in (111 mm)
7-1/2 in (190 mm)
