RP-6 Remote Control Processor
4
RP-6 REFERENCE
RELAYSIRPWR
123
+ 12V DC GROUND SIGNAL IN
HIGH OUT
CONTACT B CONTACT A
CONTACT A CONTACT A CONTACT B CONTACT B
PORT 1 PORT 2 PORT 3
PORT 4
PORT 5 PORT 6
+ + + + + +
IR Output Level
POWER
EXPANSION
Model RP-6
Remote Control Processor
STATUS
RP-6 CONNECTION OPTIONS
The following diagram shows just some of the common connection scenarios. There is a
virtually unlimited number of connection possibilities and devices that can be controlled.
Bi-Color Status LED
USB Programming Port
RS-485 Expansion Port
Six (6) Multi-Purpose Output Ports
IR Output Level
Adjustment Pots
Removable Header for Connection
to IR Receivers, IR Keypads, RTI RF
Receivers, & Contact Closures.
