PortaMonitorPage 7-8 • Switches and menus
ATTACK Integration time constant:
NORM (according to scale standard),
1 ms, 0.1 ms
PEAKHOLD Peakhold mode and reset time:
OFF, 2.5 s, 4.0 s, MAN (clear by use of RESET
key). This setting is functional parallel with the
identical preset in the PPM-DIGITAL menu.
SUM/DIF-GAIN Additional gain for sum/difference display:
-6 dB, -3 dB. This setting is functional parallel with
the identical preset in the PPM-DIGITAL menu.
COLOR-NORM Bargraph color below reference or operation field.
-OPFIELD Color for operation field
-HEADROOM Color above reference
-PEAKHOLD Color for peakhold display
-GRID Color for grid and text
7.7.7. Submenu: PPM-DIGITAL
SCALE Standard selection
Digital (absolute) scales: 0 to -60 dB FS,
0 to -20 dB FS.
Analog (equivalent) scales: DIN+5, DIN+10,
NORDIC, BRIIa, BRIIb, VU+LEADa, ZOOM 20
HEADROOM [dB] Headroom field definition above reference (color
change). Adjustable in a range of 5 dB to 20 dB in
1 dB steps.
OP-FIELD [dB] Operation field definition below reference (color
change). Adjustable in a range of 0 dB to 15 dB in
1 dB steps.
ATTACK-PPM/PH Integration time constant for PPM- and (PH)
peakhold display: 0.1 ms, 1 ms, 10 ms, NORM
(according to scale standard) or SAMPLE or
PPM/PH: SMPL/SMPL; 10 ms/SMPL; 1 ms/SMPL;
0.1 ms/SMPL; or when using quasi-analog scales:
NORM; 1 ms; 0.1 ms; SAMPLE; NORM/SMPL;
1 ms/SMPL; 0.1 ms/SMPL; SMPL/SMPL;
DC-FILTER DC-filter selection: 5 Hz, 10 Hz, 20 Hz, OFF
PEAKHOLD Peakhold reset time: OFF, 2.5 s, 4.0 s, MAN (clear
by use of RESET key). This setting is functional
parallel with the identical preset in the
PPM-ANALOG menu.
SUM/DIF-GAIN Additional gain for sum/difference display:
-6 dB, -3 dB. This setting is functional parallel with
the identical preset in the PPM-ANALOG menu.
COLOR-NORM Bargraph color below reference or operation field.
-OPFIELD Color for operation field
-HEADROOM Color above reference
-PEAKHOLD Color for peakhold display
-GRID Color for grid and text
