PortaMonitor Specifications • Page B-1
Appendix B:
Specifications
General
Supply voltage
• 1061 - 1064: 24 V DC ±10 %
• 1064V12: 12 V DC ±10 %
• 1064V5: 5 V DC ±3 %
Current drain permanent
• 1061/1062: max. 530 mA
• 1063/1064: max. 580 mA
• 1064V12: max. 1.2 A
• 1064V5: 2.5 A
Current drain start up
• 1061 - 1064: max. 750 mA
• 1064V12: max. 1.5 A
• 1064V5: 4 A
Operating temperature range: 0° to +45° celsius
Maximum input level: +21 dBu
Adjustable range for reading reference: -3 dBu to +18 dBu
Inputs: electronically balanced
CMRR: min. 60 dB
Input impedance (30 Hz and 20 kHz): min. 10 kΩ
Digital input: AES/EBU
Input impedance: 110 Ω or Hi-Z
Sample rate: 32 kHz to 48 kHz
Digital output: AES/EBU (buffered)
Gewicht: approx. 1100 g net
Connector: 3 x XLR-F (1061/1062)
1 x 25pin sub-D (1063/1064)
1 x 15pin sub-D (remote)
1 x flange connector type 710
Dimensions: 176,5 x 125,5 x 61,5 mm
Display
Display: Colour TFT 111 x 83 mm
Color: 8
Viewing direction: 6 o’ clock
horizontal +/-45°
vertical +10°/-34°
Contrast: > 85 with optimal viewing direction
Note:
The built-in display has a very high resolution. Even with the most advanced
techniques, a small number of pixel defects is inevitable. The manufacturer of
the display specifies a maximum of 6 active or passive pixel defects.
RTW guarantees these specifications to be met by their products.
