ES-2310C User Manual
Publication date: Aug., 2010
Revision A5
129
Function name:
VIP Port Setting
Function description:
When the port is set as VIP Port, the packets enter this port and will have
highest transmitting priority. For example, as you choose port 2 is VIP Port,
simultaneously transmit packets from port 2 and port 3 to port 1 at speed of
100MB and let congestion happen. The packets for port 3 will be dropped
because the packets from port 2 owns highest precedence. For the sake of
this function taking effect, you must choose Scheduling Method of Strict
Priority ahead.
Parameter description:
VIP Port:
Just tick the check box (
) to select any port( port 1~10) as the VIP Port.
Then, click the <Apply> button to have the setting taken effect.
Fig. 3-64
