Chapter 8 Man-machine Interface Operating Instruction
There are sixteen keys on the man-machine operating panel, the function of each
among which is as shown on the key.
8.1 Introduction to the Main Interface
(1) Idle Interface (display system time: day/month /year)
(2) Pause Interface
(3) Running Interface (display run time of the selected file:
hour/minute/second)
File：XX File Number：XXXX
Max Power：XX.X%
Run Speed：XXX mm/s
System Idle: 25/12/2010
Figure: 8.1-1
Figure: 8.1-2
Figure: 8.1-3
File：XX File Number：XXXX
Max Power：XX.X%
Run Speed：XXX mm/s
System Paused: 00.12.40
File：XX File Number：XXXX
Max Power：XX.X%
Run Speed：XXX mm/s
System Run: 00.12.40
