(4) Run finished interface (display the total run time of the last file:
h./min./sec.)
In this interface, if “ESC” key is pushed down, the interface will return to idle
interface, that is to say, the Figure 8.1-1.
The interface in Figure 8.1-1 shows when the system is idle. “File” means the
number of the memory file presently selected by the operator. If it is 00, it means the
memory file is not selected. “File Number” means the processing times of the current
file number. “Max. Energy” and “Speed” separately mean the maximum energy and
the engraving speed set on the keyboard. Maximum energy is expressed by
percentage and accurate to 0.1%. The unit of processing speed is millimeter a second
(mm/s). When there is a laser tube, the interface only shows the maximum energy of
this tube as shown in the above figure. If there are two laser tubes that are enabled, the
interface show the maximum energy of two laser tubes. The main idle interface is
taken for example as shown in Figure 8.1-5. On the interface shown in Figures 8.1-1
and 8.1-4, you can press any keys on the keyboard. On the interfaces shown in Figure
8.1-2 and 8.1-3, some keys can’t respond.
8.2 Introduction to the Keys
(1) Reset key
File：XX File Number：XXXX
Max Power：XX.X%/ XX.X%
Run Speed：XXX mm/s
System Idle: 25/12/2010
Figure: 8.1-5
Reset
File：XX File Number：XXXX
Max Power：XX.X%
Run Speed：XXX mm/s
Work Finished: 00.12.40
Figure: 8.1-4
