Ruijie Reyee RG-RAP2200 User Manual

Hardware Installation and Reference Guide Installing the Access Point
10
 Keep the device clean and dust-free.
 Disconnect the device before cleaning it.
 Do not wipe the device with a damp cloth.
 Do not wash the device with liquid.
 Do not open the enclosure when the AP is working.
 Fasten the device tightly.
3.4 Installing the Access Point
 Ceiling Mount
1. Attach the mounting bracket on the ceiling or wall, as shown in Figure 3-1.
Figure 3-1 Attaching the Mounting Bracket on the Ceiling/Wall
2. Connect the Ethernet cable to the LAN1 port. See Figure 3-2.
Figure 3-2 Connecting the Ethernet Cable to the LAN1 Port
3. Align the square feet on the rear of the AP over the mounting holes on the bracket. Slide the AP into the holes until it
clicks into place, as shown in Figure 3-3.
Figure 3-3 Fastening the AP

Ruijie Reyee RG-RAP2200 Specifications

General

Brand	Ruijie
Model	Reyee RG-RAP2200
Category	Wireless Access Point
Language	English
