Ruijie Reyee RG-RAP2200

Hardware Installation and Reference Guide Product Overview
2
Management
Ports
N/A
Anti-theft Locks
Support
LED
1 LED (green)
Power Supply
Adapter: DC 12 V/1.5 A (optional)
PoE: IEEE 802.3af/802.3at-compliant (compatible).
Power
Consumption
< 12.95W
Temperature
Operating: 0°C to 40°C (32°F to 104°F)
Storage: –40°C to 75°C (–40°F to 167°F)
Humidity
Operating: 5% to 95% RH (non-condensing)
Storage: 5% to 95% RH (non-condensing)
Installation
Ceiling/wall mount
Certification
CE
MTBF
> 250,000 H
Weight refers to the weight of host.
1.2 Product Image
The AP provides two 10/100/1000Base-T Ethernet ports (LAN1 port is PoE-capable), one power port for an external power
supply and one reset button.
Figure 1-1 Appearance of RG-RAP2200(E)
Figure 1-2 Bottom View of RG-RAP2200(E)
