Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
Featuring leading 802.11ax and MU-MIMO, Ruijie RG-RAP2260(G) supports 2 spatial streams and delivers up to 574
Mbps at 2.4 GHz and 1201 Mbps at 5 GHz. The overall dual-radio dual-band performance speeds up to 1.775 Gbps per
device, totally eliminating Gigabit wireless bottlenecks. RG-RAP2260(G) adopts either local power supply or PoE+ power
supply, and can be ceiling-mounted in indoor Wi-Fi coverage scenarios with large areas. RG-RAP2260(G) provides two
Gigabit Ethernet ports, making it possible to connect a camera or switch device to adapt to challenges in a wide variety of
deployment scenarios.
1.1 Technical Specifications
Table 1-1 RG-RAP2260(G) Technical Specifications
Support concurrent 802.11ax, 802.11ac wave2/wave1 and 802.11a/b/g/n.
802.11b/g/n/ax: 2.4 GHz to 2.4835 GHz
802.11a/n/ac/ax: 5.15 GHz to 5.35 GHz, 5.725 GHz to 5.85 GHz
Array antenna (2.4 GHz: 3dBi, 5 GHz: 3dBi)
5 GHz: up to 1201 Mbps
Up to 1.775 Gbps per AP
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16QAM@24Mbps, 64QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
OFDMA
11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps)
11a/g: -91dBm(6Mbps), -85dBm(24Mbps), -80dBm(36Mbps), -74dBm(54Mbps)
11n: -90dBm(MCS0), -70dBm(MCS7), -89dBm(MCS8), -68dBm(MCS15)
11ac: 20MHz: -88dBm(MCS0), -63dBm(MCS9)
11ac: 40MHz: -85dBm(MCS0), -60dBm(MCS9)
11ac: 80MHz: -85dBm(MCS0), -60dBm(MCS9)
11ax: 80MHz: -82dBm(MCS0), -57dBm(MCS9), -52dBm(MCS11)
≤100mw (20 dBm) (adjustable)
Transmit Power
Adjustment
194 mm x 194 mm x 35 mm (7.6 in. x 7.6 in. x 1.4 in.) (excluding brackets)
0.56 kg (excluding brackets)
