Hardware Installation and Reference Guide Product Overview
2
Two 10/100/1000BASE-T Ethernet uplink ports: LAN1/PoE port is PoE+-capable
Adapter: DC 12 V/1.5 A (optional)
PoE: IEEE 802.3at-compliant (compatible)
Operating: 0°C to 40°C (32°F to 104°F)
Storage: –40°C to 70°C (–40°F to 158°F)
Operating: 5% to 95% RH (non-condensing)
Storage: 5% to 95% RH (non-condensing)
Weight refers to the weight of host.
1.2 Product Image
The AP provides two 10/100/1000Base-T Ethernet ports (LAN1/PoE port is PoE+-capable), one power port for an external
power supply and one reset button.
Figure 1-1 Appearance of RG-RAP2260(G)
1.3 LED Indicator and Button
