Appendix B Mini-GBIC and SPF+ Module
SFP modules (Mini-GBIC module) and 10G SFP+ modules are available to address the requirements of interface types of
switch modules. You can select the Mini-GBIC module to suit your specific needs. The models and technical
specifications of some Mini-GBIC and 10G SFP+ modules are listed below. For details, see Ruijie Transceiver Installation
and Reference Guide.
Table B-1 Models and Technical Specifications of the 1000M Mini-GBIC(SFP) Module
Model
Wave
Length
(nm)
Media
Type
DDM
(Yes/No)
Intensity of
Transmitted
Light (dBm)
Intensity of
Received Light
(dBm)
Min
Max
Min
Max
Mini-GBIC-SX
850
MMF
No
-9.5
-3
-17
0
Mini-GBIC-LX
1310
SMF
No
-9.5
-3
-20
-3
GE-eSFP-SX-MM850
850
MMF
Yes
-9.5
-3
-17
0
GE-eSFP-LX-SM1310
1310
SMF
Yes
-9.5
-3
-20
-3
GE-SFP-LX-SM1310
1310
SMF
No
-9.5
-3
-20
-3
Mini-GBIC-LH40
1310
SMF
Yes
-2
3
-22
-3
GE-SFP-SX-SM1310-BIDI
1310
MMF
No
-10
-5
-17
-3
GE-SFP-SX-SM1550-BIDI
1550
MMF
No
-10
-5
-17
-3
GE-SFP-LX20-SM1310-BIDI
1310TX/15
50RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LX20-SM1550-BIDI
1550TX/13
10RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LH40-SM1310-BIDI
1310TX/15
50RX
SMF
Yes
-5
0
-24
-1
GE-SFP-LH40-SM1550-BIDI
1550TX/13
10RX
SMF
Yes
-5
0
-24
-1
Mini-GBIC-ZX50
1550
SMF
Yes
-5
0
-22
-3
Mini-GBIC-ZX80
1550
SMF
Yes
0
4.7
-22
-3
Mini-GBIC-ZX100
1550
SMF
Yes
0
5
-30
-9
GE-SFP-SX
850
MMF
No
-9.5
-3
-17
0
GE-SFP-LX
1310
SMF
No
-9.5
-3
-20
-3
Table B-2 Models of 1000M SFP Copper Module
Standard
Model
DDM (Yes/No)
1000Base-T
Mini-GBIC-GT
No
Table B-3 Module Cabling Specification
Model
Interface
Type
Fiber Type
Core Size(μm)
Cable Distance
(Max.)
Mini-GBIC-SX-MM850
LC
MMF
62.5/125
275m
50/125
550m
